sus 201 304 316l 304l 430 439 441 409 1.2mm stainless steel sheet
DQ DDQ
What is Stainless Steel ?
Stainless steel contains chromium which provides the properties of
corrosion resistance at high temperatures. Stainless steel can
withstand corrosive or chemical environments due to its smooth
surface. Stainless steel products are safe for long-term use with
excellent resistance of corrosion fatigue.
| Stainless Steel Sheet Information |
| Technique | Surface Finish | Grade Series | Thickness(mm) | Width(mm) | Application |
| Main Dimension |
| 20-850 | 1000 | 1219 | 1240 | 1250 | 1500 | Petro-chemical industry,Tanks
Construction material |
| Hot Rolled | No.1 / 2E | 201/202/
304 | 2.2-12.0 | √ | √ | √ | √ | | √ |
|
| Cold Rolled | 2B | 201/304 | 0.25-3.0 | √ | √ | √ | √ | √ | √ |
| 410S/430 | 0.25-2.0 | √ | √ | √ | √ | | |
No.4 / Hairline
Mirror / Linen
SB | 201/304 | 0.22-3.0 | √ | √ | √ | √ | √ | |
| 410S/430 | 0.25-2.0 | √ | √ | √ | √ | √ | |
| BA | 201/304 | 0.2--1.8 | √ | √ | √ | √ | | |
| 410S/430 | 0.25-2.0 | √ | √ | √ | √ | | |
| 2BA | √ | √ | √ | √ | | |
| Chemical composition and mechanical properties of stainless steel
coils |
| Grade | Chemical Composition (%) | Mechanieal Performece |
| C | Si | Mn | P | S | Ni | Cr | Mo | Hardness |
| 201 | ≤0.15 | ≤1.00 | 5.5/7.5 | ≤0.060 | ≤0.030 | 3.5/5.5 | 16.0/18.0 | - | HB≤241,HRB≤100, HV≤240 |
| 304 | ≤0.08 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 8.0/11.0 | 18.00/20.00 | - | HB≤187,HRB≤90,HV≤200 |
| 316 | ≤0.08 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 10.00/14.00 | 16.0/18.0 | 2.00/3.00 | HB≤187, HRB≤90 HV≤200 |
| 316L | ≤0.03 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 10.00/14.00 | 16.0/18.0 | 2.00/3.00 | HB≤187, HRB≤90 HV≤200 |
| 410 | ≤0.15 | ≤1.00 | ≤1.25 | ≤0.060 | ≤0.030 | ≤0.060 | 11.5/13.5 | - | HB≤183, HRB≤88 HV≤200 |
| 430 | ≤0.12 | ≤1.00 | ≤1.25 | ≤0.040 | ≤0.03 | - | 16.00/18.00 | - | HB≤183, HRB≤88 HV≤200
|
Packing details
1 Sheets covered with wooden plate for protection in
transportation.
2. All sheets will be loaded in strong wooden packages.
3. Every cartons loaded with good shoring and strengthening.
4. Take container loading pictures and seal the container.
5. Transportation speed is quick. And keep customer each step informed.
What is 2B ?
2B Finished by heat treatment , picking or equipvalent cold rolling
, followed by skin pass to obtain adequate luster surface.
What is BA ?
BA surface finished is Bright heat treatment after cold rolling.
What is NO.4 ?
No.4, also called #4, satin or directional finish, is an
unidirectional finish obtained with a 100-400 grit abrasive
depending on requirements. High grit numbers create finer polishing
lines and more reflective finishes.
What is Hairline finished ?
Hairline referred to as "the HL",it’s grain as fine as hair,
straight and continuous, delicate with oil paints on the surface.
It has slightly lower reflective rate than satin stainless steel
sheet.
What is Mirror finished ?
Mirror finish is produced by progressively using finer abrasives
and finishing with extremely fine buffing compounds. Mirror finish is also called 8K, No.8 and polish finish, which is
the most reflective mirror finish with high quality to similar as
glass mirror. The final surface is blemish free with a high degree of image
clarity and is the true mirror finish.
